Lathe bed is made of thick wall steel pipe welding and become, after high temperature tempering treatment, ensure a little deformation, good rigidity and strength.

Y axis adopt double motor drive, selection of matching, to ensure the smooth movement.

Mixer adopts high precision gear rack transmission, high precision, speed and strength.

Mixer adopts imported square linear guide, precision is high, bearing large redundancy, long service life.

Electromechanical provided design, selection of all kinds of electrical accessories, minimize failure rate.

Mixer machine equipped with water tank and automatic water cooling system.

In pieces all the dust waterproof design, all-round protection machine transmission parts.

Machine type XK - 1325 heavy stone engraving machine

Work schedule 1300 * 2500 * 300

Machine structure of thick wall tube structure of lathe bed, lu: xingcai mesa

The machine size 2800 * 3050 * 2800 (mm)

Engraving depth (300 mm)

The maximum speed carving 20 m/min

The machining accuracy < 0.05/300 mm

Carving instruction G code

Spindle power 5.5 kw water-cooled spindle

Cutter diameter

Φ Φ 6 Φ 12.7 3.175

XYZ guide

Three axis square linear guide

XY high precision rack gear transmission mode; The Z axis high precision ball screw drive

Working voltage AC380V, 50 hz

The operating system d macro system/DSP or specified system

Fixed clamp fixed materials
